产品描述
产品参数
功率：0.75-200kW
口径：DN50-DN400mm
扬程：4.5-53m
流量：6-2000m3 /h
温度：0ºC~+40ºC
电压：380V
| Pump model | Speed (r/min) | flow (m 3/h) | Head(m) | Motor power (kW) | Eff.η (%) | Dia. (mm) | Weight (kg) |
| SS200.272D-M6/7.5 | 980 | 350 | 4.5 | 7.5 | 70 | 200 | 260 |
| SS200.400AD-M6/30 | 980 | 420 | 15 | 30 | 74 | 200 | 630 |
| SS200.400BD-M6/30 | 980 | 280 | 22 | 30 | 76 | 200 | 630 |
| SS200.425D-M6/37 | 980 | 350 | 24.5 | 37 | 75 | 200 | 740 |
| SS250.275D-M6/7.5 | 980 | 400 | 4 | 7.5 | 62 | 250 | 300 |
| SS250.298B-M6/11 | 980 | 400 | 6 | 11 | 69 | 250 | 390 |
| SS250.400D-M6/30 | 980 | 500 | 15 | 30 | 75 | 250 | 700 |
| SS250.425D-M6/37 | 980 | 500 | 16.5 | 37 | 77 | 250 | 800 |
| SS250.430D-M6/45 | 980 | 600 | 20 | 45 | 78 | 250 | 950 |
| SS250.495D-M6/55 | 980 | 400 | 30 | 55 | 72 | 250 | 1100 |
| SS250.480D-M6/75 | 980 | 600 | 30 | 75 | 76 | 250 | 1400 |
| SS300.335B-M6/22 | 980 | 900 | 5 | 22 | 70 | 300 | 670 |
| SS300.345B-M6/30 | 980 | 700 | 10 | 30 | 70 | 300 | 720 |
| SS300.358B-M6/37 | 980 | 900 | 10 | 37 | 75 | 300 | 840 |
| SS300.405B-M6/45 | 980 | 700 | 16 | 45 | 78 | 300 | 1100 |
| SS300.458D-M6/55 | 980 | 600 | 22 | 55 | 75 | 300 | 1200 |
| SS300.415B-M6/55 | 980 | 850 | 15 | 55 | 78 | 300 | 1100 |
| SS300.475D-M6/75 | 980 | 850 | 22 | 75 | 78 | 300 | 1450 |
| SS300.485D-M6/90 | 980 | 950 | 25 | 90 | 79 | 300 | 1800 |
| SS350.335B-M6/30 | 980 | 1000 | 7 | 30 | 75 | 350 | 740 |
| SS350.372B-M6/30 | 980 | 1000 | 6 | 30 | 75 | 350 | 760 |
| SS350.345B-M6/37 | 980 | 1000 | 9.5 | 37 | 75 | 350 | 900 |
| SS350.380B-M6/37 | 980 | 1300 | 6 | 37 | 77 | 350 | 850 |
| SS350.358B-M6/45 | 980 | 1300 | 9.5 | 45 | 78 | 350 | 1100 |
| SS350.385B-M6/55 | 980 | 1100 | 10 | 55 | 75 | 350 | 1200 |
| SS350.414B-M6/75 | 980 | 1300 | 15 | 75 | 78 | 350 | 1400 |
| SS350.450AB-M6/90 | 980 | 1300 | 18 | 90 | 78 | 350 | 1500 |
| SS350.450BB-M6/90 | 980 | 1500 | 15 | 90 | 80 | 350 | 1500 |
| SS350.487B-M6/110 | 980 | 1600 | 18 | 110 | 79 | 350 | 2350 |
| SS400.425B-M6/75 | 980 | 1500 | 10 | 75 | 80 | 400 | 1500 |
| SS400.506B-M6/90 | 980 | 2000 | 10 | 90 | 75 | 400 | 1750 |
| SS400.487B-M6/110 | 980 | 2000 | 12 | 110 | 79 | 400 | 2300 |
| SS400.500B-M8/132 | 740 | 2000 | 15 | 132 | 81 | 400 | 2500 |
| SS400.580B-M8/160 | 740 | 1600 | 25 | 160 | 76 | 400 | 2900 |
| SS400.590B-M8/185 | 740 | 2000 | 23 | 185 | 81 | 400 | 3200 |
| SS400.600B-M8/200 | 740 | 2000 | 25 | 200 | 80 | 400 | 3500 |
| 4P or 4-Stage Motor | |||||||
| SS50.180D-M4/0.75 | 1450 | 10 | 10 | 0.75 | 50 | 50 | 50 |
| SS65.200D-M4/1.5 | 1450 | 25 | 10 | 1.5 | 60 | 65 | 60 |
| SS65.190C-M4/1.5 | 1450 | 25 | 9 | 1.5 | 35 | 65 | 62 |
| SS65.220D-M4/1.5 | 1450 | 18 | 13.5 | 1.5 | 50 | 65 | 69 |
| SS65.223D-M4/2.2 | 1450 | 23 | 14 | 2.2 | 50 | 65 | 70 |
| SS65.246D-M4/4 | 1450 | 30 | 18 | 4 | 55 | 65 | 130 |
| SS80.200D-M4/1.5 | 1450 | 30 | 10 | 1.5 | 60 | 80 | 60 |
| SS80.190C-M4/1.5 | 1450 | 30 | 8 | 1.5 | 40 | 80 | 62 |
| SS80.200D-M4/2.2 | 1450 | 40 | 10 | 2.2 | 55 | 80 | 72 |
| SS80.203C-M4/2.2 | 1450 | 40 | 9 | 2.2 | 45 | 80 | 75 |
| SS80.230D-M4/4 | 1450 | 45 | 15 | 4 | 57 | 80 | 130 |
| SS80.223C-M4/4 | 1450 | 50 | 12 | 4 | 45 | 80 | 135 |
| SS80.247D-M4/5.5 | 1450 | 40 | 22 | 5.5 | 55 | 80 | 180 |
| SS80.257D-M4/7.5 | 1450 | 55 | 22 | 7.5 | 62 | 80 | 200 |
| SS80.335D-M4/11 | 1450 | 45 | 38 | 11 | 56 | 80 | 300 |
| SS80.360D-M4/15 | 1450 | 50 | 45 | 15 | 55 | 80 | 324 |
| SS100.150M-M4/1.5 | 1450 | 45 | 6 | 1.5 | 66 | 100 | 105 |
| SS100.170M-M4/2.2 | 1450 | 60 | 7 | 2.2 | 69 | 100 | 126 |
| SS100.230D-M4/4 | 1450 | 75 | 12 | 4 | 70 | 100 | 130 |
| SS100.240D-M4/5.5 | 1450 | 95 | 13.5 | 5.5 | 73 | 100 | 200 |
| SS100.257D-M4/7.5 | 1450 | 100 | 15 | 7.5 | 65 | 100 | 219 |
| SS100.262D-M4/11 | 1450 | `90 | 22 | 11 | 62 | 100 | 270 |
| SS100.280D-M4/15 | 1450 | 100 | 26 | 15 | 65 | 100 | 285 |
| SS100.315D-M4/18.5 | 1450 | 110 | 28.5 | 18.5 | 63 | 100 | 450 |
| SS150.153M-M4/2.2 | 1450 | 115 | 4.5 | 2.2 | 65 | 150 | 156 |
| SS150.173M-M4/4 | 1450 | 140 | 6.5 | 4 | 73 | 150 | 179 |
| SS150.190D-M4/4 | 1450 | 130 | 6 | 4 | 66 | 150 | 201 |
| SS150.200D-M4/5.5 | 1450 | 180 | 6 | 5.5 | 73 | 150 | 210 |
| SS150.190M-M4/5.5 | 1450 | 160 | 9 | 5.5 | 74 | 150 | 199 |
| SS150.220D-M4/7.5 | 1450 | 120 | 12 | 7.5 | 70 | 150 | 230 |
| SS150.238D-M4/7.5 | 1450 | 250 | 6 | 7.5 | 67 | 150 | 245 |
| SS150.196M-M4/7.5 | 1450 | 240 | 7.5 | 7.5 | 82 | 150 | 220 |
| SS150.262D-M4/11 | 1450 | 145 | 15 | 11 | 65 | 150 | 270 |
| SS150.280AD-M4/15 | 1450 | 200 | 15 | 15 | 74 | 150 | 285 |
| SS150.280BD-M4/15 | 1450 | 130 | 22 | 15 | 65 | 150 | 285 |
| SS150.296D-M4/18.5 | 1450 | 170 | 22 | 18.5 | 73 | 150 | 350 |
| SS150.302D-M4/22 | 1450 | 200 | 22 | 22 | 71 | 150 | 380 |
| SS150.325D-M4/22 | 1450 | 135 | 30 | 22 | 69 | 150 | 380 |
| SS200.230B-M4/11 | 1450 | 210 | 10 | 11 | 65 | 200 | 270 |
| SS200.240B-M4/15 | 1450 | 300 | 10 | 15 | 68 | 200 | 300 |
| SS200.277D-M4/18.5 | 1450 | 300 | 15 | 18.5 | 75 | 200 | 450 |
| SS200.290D-M4/22 | 1450 | 250 | 18 | 22 | 68 | 200 | 455 |
| SS200.260B-M4/22 | 1450 | 450 | 10 | 22 | 72 | 200 | 455 |
| SS200.345B-M4/37 | 1450 | 250 | 30 | 37 | 65 | 200 | 695 |
| SS200.367B-M4/45 | 1450 | 280 | 30 | 45 | 67 | 200 | 875 |
| SS200.372B-M4/55 | 1450 | 250 | 40 | 55 | 69 | 200 | 903 |
| SS200.395B-M4/75 | 1450 | 280 | 53 | 75 | 72 | 200 | 995 |
| SS250.240D-M4/15 | 500 | 6 | 15 | 71 | 250 | 380 | |
| SS250.298B-M4/18.5 | 600 | 6 | 18.5 | 71 | 250 | 420 | |
| SS250.298B-M4/22 | 700 | 6 | 22 | 73 | 250 | 445 | |
| SS300.288M-M4/45 | 1450 | 500 | 19 | 45 | 74 | 300 | 845 |
| SS300.306M-M4/55 | 1450 | 600 | 22 | 55 | 81 | 300 | 886 |
| SS300.335M-M4/75 | 1450 | 650 | 26 | 75 | 80 | 300 | 997 |
| SS250.400B-M4/90 | 1450 | 450 | 40 | 90 | 77 | 250 | 1130 |
| SS250.430B-M4/110 | 1450 | 500 | 45 | 110 | 79 | 250 | 1250 |
| 2P or 2-Stage Motor | |||||||
| SS50.98V-M2/0.37 | 2850 | 9 | 6 | 0.37 | 31 | 50 | 15 |
| SS50.130V-M2/0.75 | 2850 | 12 | 8 | 0.75 | 36 | 50 | 16 |
| SS50.105D-M2/0.75 | 2850 | 10 | 10 | 0.75 | 48 | 50 | 30 |
| SS50.130D-M2/1.5 | 2850 | 18 | 15 | 1.5 | 60 | 50 | 33 |
| SS50.143D-M2/2.2 | 2850 | 15 | 22 | 2.2 | 45 | 50 | 50 |
| SS50.158D-M2/4 | 2850 | 18 | 30 | 4 | 50 | 50 | 62 |
| SS50.180D-M2/5.5 | 2850 | 18 | 40 | 5.5 | 50 | 50 | 68 |
| SS65.147D-M2/4 | 2850 | 30 | 22 | 4 | 62 | 65 | 66 |
| SS65.175D-M2/5.5 | 2850 | 30 | 32 | 5.5 | 58 | 65 | 70 |
| SS65.180D-M2/7.5 | 2850 | 25 | 40 | 7.5 | 55 | 65 | 120 |
| SS80.148D-M2/5.5 | 2850 | 35 | 22 | 5.5 | 55 | 80 | 88 |
| SS80.173D-M2/7.5 | 2850 | 55 | 25 | 7.5 | 56 | 80 | 128 |
| SS80.200D-M2/11 | 2850 | 45 | 40 | 11 | 60 | 80 | 180 |
| SS80.215D-M2/15 | 2850 | 50 | 45 | 15 | 55 | 80 | 210 |
| SS100.175D-M2/11 | 2850 | 65 | 30 | 11 | 60 | 100 | 219 |
| SS100.178D-M2/15 | 2850 | 80 | 30 | 15 | 65 | 100 | 220 |
| SS100.190D-M2/18.5 | 2850 | 60 | 50 | 18.5 | 52 | 100 | 260 |
| SS100.194D-M2/22 | 2850 | 70 | 50 | 22 | 52 | 100 | 320 |
| SS100.205D-M2/22 | 2850 | 60 | 60 | 22 | 53 | 100 | 321 |
