Product application
It is mainly used in the pushing flow of various oxidation ditches and the mixing of biochemical tanks in the process of municipal engineering and industrial sewage treatment. It can also be used for river antifreeze, landscape water circulation, etc. through pushing flow, it can create water flow, so as to improve the water quality, increase the oxygen content in the water, and effectively prevent the sedimentation of suspended solids
| Quantity: | |
|---|---|
Product Description
Product features
High quality imported fully enclosed self-lubricating bearing with long service life.
The special cable manufacturing process can completely prevent the water from entering the motor through the small gap between each phase line and line when the cable skin is damaged or the front end of the cable invades the water, resulting in the damage of the motor.
Two independent mechanical seals ensure long-term reliable operation of submersible motor.
The blade of water ejector can be made of PU orGFRP, which is swept back and has self-cleaning function; The smooth streamline surface of the blade pulp makes the thrust evenly distributed.
The gear reducer of submersible thruster adopts planetary gear reducer, which has safe and stable operation and long service life.
The mixer is equipped with leakage sensor and stator winding overtemperature detection device (PTC).
Technical data
Power Supply：Three-phase 380V 50Hz
Working mode: S1
Protectio grade: IP68
Insulation class：Class F (Class H is optional)
Temperature range [°C]：≤40℃
Environment temperature：0-40℃
Density: Less than 1.05×103 kg/m3
PH value：5-9
Installation mode：Submersible horizontal installation
Maximum submergence depth: 20m
