Blower for Aquaculture Roots Blower with Electric Motors

Product Description

PRB is a displacement blower, the pressure can be adjusted according to the requirement of the user in allowing range, there are two impellers in the blower body which rotate in the opposite direction, in order to let the impeller rotate, there are some tiny gap between the impeller to body impeller to impeller. When the impeller rotates through the suction inlet, it can gather an amount of air between the body and impeller, then the impeller go on rotating, and the air will be pressured, the pressure in the body will rise, finally the air has been send to the outlet.

Wide range of capacity and pressure.

Calibre:  32mm-400mm (1.25 "-16")

Capacity:  0.38-283m3/min (13-9985CFM)

Pressure:  The pressure of one-stage PRB type up to 8000mmAq (0.8kgf/cm2)

  Delivers completely oil-free air.

  Low oscillation and low noise by dynamic balance which revised by computer.

  Smaller change in capacity against change in pressure.

  High efficiency due to special impeller design, great air-delivery low power.

  Simpler and solider structure, less trouble.

  Highest quality pilot & accurate great applied, long life and low noise assured.

  Standardized product with strict quality control.

  Our rotor has used the most advanced technic, one time for  all  working  process  of  the  six-shaft  method,  to  enhance the precision.

Application of Roots blower:

Waste water treatment, ash treatment after combustion, dust collection device, dyeing and finishing paper equipment, vacuum dehydration, flue gas desulfurization, environmental regulation equipment, exhaust, drying, air transportation, gas and powder particle transportation, aquaculture, the use of air pressure transportation, liquid mixing
